M71 series M7180Hx2000Horizontal shaft Rectangular table surface Grinders/grinding machine

M71 series M7180Hx2000Horizontal shaft Rectangular table surface Grinders/grinding machine

  • Min.Order Quantity: 1 Set
  • Supply Ability: 30 Sets per Month
  • Port: qingdao
  • Payment Terms: L/C,T/T,Western Union
Get Latest Price:
  • *Quantity: Set/Sets
| Factory
Experience:2004-04-14
Buyer Protection

- Guaranteed Secure Payments on Every Order

- Refund if your item is not delivered or as described

- Buyer Protection after order confirmation

Latest Browsing
Product Details
  • Place of Origin:  China
  • Brand Name:  xinhe hongxin
  • Model Number:  M71

M71 series Horizontal shaft Rectangular table surface Grinders/grinding machine    M7180H*2000



The M71 series machine is used for grinding various parts of surface in machinery plant.It is a new product on the foundation of M7150 surface grinding machine improved.It is suitable to grinding the variours part's surface in machinery industry.Electrical use new international standard,which are use to replace electrical interlocking safety device,easy operation.Grinder smooth movement,high reliability,low nose,optimum adaptation,easy to operate.



  • Place of Origin:  China
  • Brand Name:  xinhe hongxin
  • Model Number:  M71

Table Diameter(mm) 2000X800

Max  worktable cross movement distance(mm) 885

Max worktable horizonal movement distance(mm) 2250

Distance between spindle and table(mm) 900

Worktable max loading(Kgs) 2300

Worktable rotaion speed (m/min) 7-25

Scale of handwheel for cross feed 0.01mm per gra. 2 mm per rev.

Auto cross feed 2-20mm

cross rapid movement speed 50HZ 1500 mm/min

Vertical feeding for handwheel:0.002 per gra. 0.5mm per rev.

Auto vertical feeding 0.005-0.04mm

Vertical rapid movement speed:230 mm/min

Grinding wheel size:500x20-50x127mm

Spindle speed 50HZ 950 mm/min  60HZ 1150mm/min

Spindle motor:15HP

Cross motor:oil pressure

Up and down motor:1/2HP

Oil pressure motor:10HP

Flush motor:1/4HP

Szie for machine:(L X W X H ) 6000 X 3360 X 2850mm

Net/Gross weight:15500/17500Kgs
